HP E24mv G4 User Manual



11

How to order parts
The HP authorized repair center can purchase the power board from HP.
Power board
Description HP spare part number Manufacturer part number
PSU E24mv G4 1
st
Source
N12314-001
PLPCKE421GQA2
PSU E24mv G4 2
nd
Source
N12314-002
PLPCKE481AQA1
PSU E24mv G4 3
rd
Source
N12314-003
PLPCLE481AQA3
Capacitors and connectors are available for purchase from the following EU distributors:
 Farnell: Farnell UK - Electronic Components Distributor
 RS Component: Capacitors | RS Components (rs-online.com)
 tme Component: Transfer Multisort Elektronik
 Digi-Key: Digikey Electronics
Capacitors by distributor
Component description Location
Component
distributor
Distributor part number
EC 470U 20% 25V 10*12mm
10000 hr -- RF1E
C904
RS 25ZLJ470M10X12.5
EC 470uF 20% 25V 10x12mm C906/C914/C916 Digi-Key 25YXG470MEFC10X12.5
12 Latch 1
13 SPRING 2
14 SHIELD_PLATE 1
15 HINGE ASS'Y 1
16 HINGE ASS'Y 1
17 HINGE ASS'Y 1
18 LOGO HP 56 1
19 stand ass'y 1
20 BASE_ASS’Y 1
21 LOGO HP 12 1
22 FILM 1
23 HINGE ASS'Y 1
S1 SCREW M3 3(MIDDLE FRAME/PANEL) 13
S2 SCREW D3 6(MAIN BOARD/POWER BOARD/MAINFRAME) 7
S3 SCREW -- 6mm(POWER BOARD/MAINFRAME) 1
S4 SCREW -- 10(REAR COVER/MAINFRAME) 4
S5 SCREW 5(Latch/REAR COVER) 2
S6 SCREW 5(KEY BOARD/REAR COVER) 6

HP E24mv G4 Specifications

General

Color gamut	72 %
Pixel pitch	0.274 x 0.274 mm
Screen shape	Flat
Display diagonal	23.8 \
Surface hardness	3H
Anti-glare screen	Yes
Native aspect ratio	16:9
Vertical scan range	50 - 60 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 80 kHz
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1000:1
Display number of colors	-
Display diagonal (metric)	60.45 cm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1280 x 800, 1440 x 900 (WXGA+), 1440 x 900, 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
HDMI version	1.4
DisplayPort version	1.2
USB Type-A downstream ports quantity	4
Power consumption (max)	50 W
Power consumption (standby)	0.5 W
Power consumption (typical)	28 W
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Package type	Box
Package depth	411 mm
Package width	596 mm
Package height	225 mm
Package weight	10400 g
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 23 °
Height adjustment	150 mm
Panel mounting interface	100 x 100 mm
Cables included	AC, DisplayPort, HDMI, USB Type-A to USB Type-B
Certification	Australian-New Zealand MEPS; BIS; BSMI; CB; CCC; CE; CECP; CEL; cTUVus; EAC; ENERGY STAR®; FCC; GS Mark; ISO 9241-307; KC/KCC; NOM; PSB; SEPA; TCO Certified; TCO Certified Edge; TUV/GS; VCCI; Vietnam MEPS; WEEE; Low blue light; WW application; UAE; Ukraine certificates
Product color	Black, Silver
Country of origin	China
Market positioning	Business
RMS rated power	2 W
Number of speakers	2

Weight and Dimensions

Depth (with stand)	216 mm
Width (with stand)	539.4 mm
Height (with stand)	530.7 mm
Weight (with stand)	6500 g
Depth (without stand)	47 mm
Height (without stand)	355.6 mm
