HP E24q G4 User Manual

10
How to order parts
The HP authorized repair center can purchase the power board from HP
Power board
Description
HP spare part number
Manufacturer part number
SPS-PSU E24q G4 AUO
5E.4QU02.001
M97952-001 5E.4QU02.001
SPS-PSU E24q G4 BOE
5E.4QU02.002
M97953-001 5E.4QU02.002
SPS-PSU E24q G4 LGD
5E.4QU02.003
M97954-001 5E.4QU02.003
Capacitors and connectors are available for purchase from the following EU distributors:
• Farnell: Farnell UK - Electronic Components Distributor
• RS Component: Capacitors | RS Components (rs-online.com)
Capacitors by distributor
Component
description
Location
Component
distributor
Distributor part number
Capacitor 470 µF
10*12.5 5K
C706;
C707;
C708;
Farnell; RS 25ZLH470MEFC10X12.5
Connectors by distributor
Component
description
Location
Component
distributor
Distributer part number
VGA J401
RS
923-0676
HDMI J601
Farnell; RS
Molex 2086581001
Display Port J501
Farnell; RS
Molex SD-47272-0024
USB 3.0 Type B JA1
Farnell
WURTH ELEKTRONIK 692221030100
UAB A DUAL JB1
Farnell
WURTH ELEKTRONIK 692141030100
Gasket by distributor
Component Description Location
Component
Distributor
Part number of
Manufacturer/ Distributor
Gasket for HDMI
SHD
Farnell
3021717
Specification: Gasket, EMI Shielding, 17 mm Width, 17 mm Height, 1 m Length, 80 dB
To replace HDMI, must need a gasket stick on shielding.
NOTE: The connector may need to be modified to meet functionality, regulatory and safety
requirements if it is not an exact match.
You can purchase cables from the HP part store at https://partsurfer.hp.com/Search.aspx
.
NOTE: HP continually improves and changes product parts. For complete and current information
about supported parts for your computer, go to http://partsurfer.com
, select your country or region,
and then follow the on-screen instructions.
Internal and External Power Supplies are available for purchase from the following EU
distributor: EET https://www.eetgroup.com/en-eu/

HP E24q G4 Specifications

General

Color gamut	99 %
Pixel pitch	0.205 x 0.205 mm
Screen shape	Flat
Pixel density	123 ppi
Display diagonal	23.8 \
Display technology	-
Native aspect ratio	16:9
Maximum refresh rate	- Hz
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1000:1
Digital vertical frequency	50 - 60 Hz
Digital horizontal frequency	30 - 90 kHz
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 800, 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 502
HP segment	Business
Product color	Black, Silver
Country of origin	China
HDMI version	1.4
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Built-in USB hub	Yes
DisplayPort version	1.2
USB upstream port type	USB Type-B
USB Type-A downstream ports quantity	4
Pivot angle	-90 - 90 °
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
Power consumption (max)	50 W
Power consumption (standby)	0.5 W
Power consumption (typical)	24 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Package depth	225 mm
Package width	610 mm
Package height	395 mm
Package weight	8400 g
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	207 mm
Width (with stand)	539.4 mm
Height (with stand)	494.9 mm
Weight (with stand)	5700 g
Depth (without stand)	47 mm
Height (without stand)	323.3 mm
