HP E24q G4 User Manual

18
Connector repair
This procedure includes VGA, HDMI, Display port, USB3.0, USB A connectors.
The connectors are on the main board (board part number 5E.4QU01.00*).
The connectors identifiers are as follows:
Connector
Location
VGA
J401
HDMI
J601
Display Port
J501
USB 3.0 Type B
JA1
UAB A DUAL
JB1
Before repairing connectors, follow these steps:
▲ Prepare the monitor for disassembly. See Preparation for disassembly on page 11
.
Main Board
J501
J601
J401
JA1
JB1

HP E24q G4 Specifications

General

Color gamut	99 %
Pixel pitch	0.205 x 0.205 mm
Screen shape	Flat
Pixel density	123 ppi
Display diagonal	23.8 \
Display technology	-
Native aspect ratio	16:9
Maximum refresh rate	- Hz
Contrast ratio (dynamic)	5000000:1
Contrast ratio (typical)	1000:1
Digital vertical frequency	50 - 60 Hz
Digital horizontal frequency	30 - 90 kHz
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 800, 1440 x 900 (WXGA+), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 502
HP segment	Business
Product color	Black, Silver
Country of origin	China
HDMI version	1.4
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Built-in USB hub	Yes
DisplayPort version	1.2
USB upstream port type	USB Type-B
USB Type-A downstream ports quantity	4
Pivot angle	-90 - 90 °
Panel mounting interface	100 x 100 mm
AC input voltage	100 - 240 V
Power consumption (max)	50 W
Power consumption (standby)	0.5 W
Power consumption (typical)	24 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Package depth	225 mm
Package width	610 mm
Package height	395 mm
Package weight	8400 g
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	207 mm
Width (with stand)	539.4 mm
Height (with stand)	494.9 mm
Weight (with stand)	5700 g
Depth (without stand)	47 mm
Height (without stand)	323.3 mm
