HP Elite x2 G4 Tablet Service Manual

Lights
Table 2-8 Lights and their descriptions
Component Description
(1) Caps lock light On: Caps lock is on, which switches the key input to all capital
letters.
(2) Fn lock light On: The fn key is locked. For more information, see Hot keys
(select products only) on page 20.
(3) Mute light ● On: Computer sound is o.
● O: Computer sound is on.
(4) Microphone mute light ● On: Microphone is o.
● O: Microphone is on.
(5) Num lk light On: Num lock is on.
(6) Wireless light On: An integrated wireless device, such as a wireless local area
network (WLAN) device and/or a Bluetooth® device, is on.
NOTE: On some models, the wireless light is amber when all
wireless devices are o.
(7) Sharing or presenting light On: Sharing is on.
(8) Call answer light On: Call answer is on.
(9) Call end light On: Call end is on.
18 Chapter 2 Components

HP Elite x2 G4 Tablet Specifications

General

Operating System	Windows 10 Pro
Battery Life	Up to 10 hours
Graphics	Intel UHD Graphics 620
Camera	5MP front-facing, 8MP rear-facing
Processor	Intel Core i5 or i7 (8th Gen)
RAM	Up to 16GB LPDDR3
Storage	Up to 1TB PCIe NVMe SSD
Weight	0.82 kg (tablet only)
Ports	2 x USB-C, 1 x USB-A, 1 x headphone/microphone combo
Wireless	Bluetooth 5
Audio	Bang & Olufsen, dual speakers
Battery	47 Wh Li-ion polymer
Dimensions	0.35 in
