Display panel
Table 6-1 Display panel and back cover descriptions and part numbers
Description Spare part number
Back cover L67414-001
Display panel, WUXGA+ L67406-001
Display panel, WUXGA+, privacy L67408-001
Display panel, 3k × 2k L67407-001
IMPORTANT: Make special note of each screw size and location during removal and replacement.
Before removing the display panel, follow these steps:
▲ Prepare the computer for disassembly (Preparation for disassembly on page 35).
Remove the display panel:
1. Lift the kickstand (1), and then remove the four Torx T5 1.8 × 2.0 screws (2) securing the back cover.
38 Chapter 6 Removal and replacement procedures for authorized service provider parts
