Table 3-1 Computer major components and their descriptions
Item Component Spare part number
(1) Display panel, touch screen
WUXGA+ L67406-001
WUXGA+, privacy L67408-001
3k × 2k L67407-001
(2) Battery, 2 cell, 47 Wh L46601-005
(3) WWAN module
NOTE: The WWAN protective tape kit is available as spare part number L67434-001.
Intel XMM 7360 LTE-Advanced (CAT 9) L15398-006
Intel XMM 7560 LTE-Advanced Pro (CAT 16) L27188-005
(4) Solid-state drive (M.2)
2 TB, PCIe, TLC L67401-001
1 TB, PCIe, TLC L67397-001
512 GB, PCIe, TLC + 32 GB Optane memory L67405-001
512 GB, SATA-3, self-encrypting drive (SED), Opal 2, TLC L674021-001
512 GB, PCIe, TLC L67403-001
512 GB, PCIe L67404-001
256 GB, SATA-3, self-encrypting drive (SED), Opal 2, TLC L67398-001
256 GB, PCIe, TLC L67399-001
256 GB, PCIe L67400-001
128 GB, SATA-3, TLC L67398-001
(5) USB bracket L67425-001
(6) Heat sink with fan (includes replacement thermal material) L67416-001
(7) System board (includes integrated processor, heat sink, and replacement thermal
material) (see System board on page 60)
Intel Core i5-8665U processor and 16 GB of system memory L67395-601
Intel Core i5-8665U processor and 8 GB of system memory L67393-601
Intel Core i5-8565U processor and 16 GB of system memory L67394-601
Intel Core i7-8565U processor and 8 GB of system memory L67391-601
Intel Core i7-8365U processor and 16 GB of system memory L67389-601
Intel Core i7-8365U processor and 8 GB of system memory L67390-601
Intel Core i5-8265U processor and 16 GB of system memory L67392-601
Intel Core i7-8265U processor and 8 GB of system memory L67388-601
(8) Speaker Kit (includes left and right antennas)
Includes WLAN antennas L67428-001
24 Chapter 3 Illustrated parts catalog
