Miscellaneous plastic parts
Component appearance varies depending on model.
Table 2-2 Miscellaneous plastic parts and their descriptions
Item Description
(1) Rear cover (main)
For use in standard models
For use in healthcare models
(2) Rear I/O cover
For use in standard models
For use in healthcare models
(3) Rear port cover
For use in standard models
For use in healthcare models
(4) Webcam holder (located under the webcam)
(5) Webcam cover
*
Optical drive cover (for use in models without an optical drive)
For use in standard models
For use in healthcare models
*
Card reader cover (for use in models without a card reader)
*
Fingerprint sensor cover (for use in models with out a ngerprint sensor)
*
VESA cover (for use in models with out a stand)
*
Optical drive bezel
For use in standard models
For use in healthcare models
10 Chapter 2 Illustrated parts catalog
