Fingerprint reader board
NOTE: The ngerprint reader board spare part kit does not include the cable. The board cable is available
using spare part number L52657-001.
Table 5-11 Fingerprint reader board descriptions and part numbers
Description Spare part number
Fingerprint reader board for use in models with a stamped nish L52651-001
Before removing the ngerprint reader board, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 26).
2. Remove the bottom cover (see Bottom cover and rubber feet on page 27).
3. Remove the battery (see Battery on page 30).
4. Remove the hard drive (see Hard drive, drive rubber holder, and cable on page 35).
Remove the ngerprint reader board:
1. Remove the Phillips M2.0 × 2.0 screw (1) that secures the ngerprint reader board bracket to the
computer.
2. Slide the bracket toward the side of the computer, and then remove it (2).
3. Disconnect the cable from the ZIF connector on the ngerprint reader board (3).
4. Remove the ngerprint reader board from the computer (4).
Reverse this procedure to install the ngerprint reader board.
Component replacement procedures 45
