3. Repeat these steps for the rail on the other side of the server.
Figure 7 Removing the rails from the server
Attaching the pedestal kit top and bottom
IMPORTANT:
In this document the server top, bottom, right and left refer to the server as faced from the front
with the server in a horizontal orientation. The pedestal kit components are referred to by the final
position with the server in a vertical orientation. For example, the pedestal kit bottom attaches to
the server right side.
HP Confidential20 Installing the server
