Power states
The server has the following power states:
• Standby power
• Full power
• Off
Table 7 Power states
DC voltage
applied?
Standby DC
voltage applied?
Power activated through the iLO 3 PC
command; or front panel power button
activated?
Power cable
plugged into
receptacle?
Power states
NoYesNoYesStandby power
YesYesYesYesFull power
NoNoNoNoOff
CAUTION: If the server is expected to remain in standby mode for more than 30 minutes, AC
power should be completely removed from the server. You can do this by switching off the circuit
breakers that are part of the building installation, disconnecting or switching off a power distribution
unit, or by physically removing the power cords from the server.
Be aware that removing AC power from the server for an extended period can drain the system
battery.
NOTE: If the power restore feature is set to Always On through the iLO 3 MP PR command, the
server automatically powers on to the full power state when the power cord is plugged in to the
server.
The HP Integrity rx2800 i4 Server User Service Guide shows the ports and power supplies located
on the rear panel of the server.
Applying standby power to the server
1. Plug the power cord into the receptacle in power supply.
2. Plug the other end of the power cord into an AC outlet.
NOTE: The LED on the power supply does not illuminate in the standby power state. The
LED is green when the server is powered on to full power.
If the power restore feature is set to Always On through the iLO 3 MP PR command, the server
automatically powers on to the full power state when the power cord is plugged into the server.
3. If the server has two power supplies, plug the second power cord into the power supply.
4. Plug the other end of the power cord into an AC outlet.
Connecting to the LAN
The server has four LAN ports that provide network connectivity. The HP Integrity rx2800 i4 Server
User Service Guide shows the available LAN ports for the server.
1. Obtain valid IP addresses for each LAN port you plan to activate.
2. Connect the LAN cable from an available LAN port into a live connection on the network.
Setting up the system
For more information on using the iLO 3 MP, see the HP Integrity iLO 3 Operations Guide.
HP Confidential26 Installing the server
