6. Unplug the mating connector.
To replace the component, reverse the removal procedure.
Removing and replacing the system board
IMPORTANT: If your system board has a TPM installed, you must order a new TPM when you
order a replacement system board.
Before replacing the system board, you must first back up the current TPM settings. See the HP-UX
operating system documentation for more information.
The TPM is not a customer-installable component. If the TPM needs to be replaced, contact an HP
authorized service provider.
CAUTION: Once the TPM is installed on your system board, it cannot be removed. If the TPM
fails, the system board needs to be replaced. Attempting to remove the TPM from the system board
will void any existing HP service contract and cause the server to fail.
1. Power off the server (“Powering off the server” (page 99)).
2. Remove all power supplies (“Removing and replacing a hot-swap power supply” (page 105)).
3. Remove all hot-plug hard drives (“Removing and replacing a hot-plug SAS hard drive” (page
104)).
4. Extend or remove the server from the rack (“Removing the server from the rack” (page 99))
or “Extending the server from the rack” (page 95)).
5. Remove the access panel (“Removing and replacing the access panel” (page 106)).
6. Remove the air baffle.
HP Confidential126 Removal and replacement procedures
