HP Integrity rx4640 Operation Guide

Chapter 2
Controls, Ports, and Indicators
Additional Controls and Indicators
19
Subsystem CPU
board
Memory
board
I/O board n/a A soldered voltage regulator has
failed—the specified board must be
replaced.
I/O VRM 12 volt 5 volt 3 volt n/a A plug-in voltage regulator has
failed—specific VRM must be replaced.
CPU VRM n/a n/a n/a n/a n/a
Fan Module 0 1 2 n/a One or both fans in a fan module has
failed—the module must be replaced.
Fan 2 is in front of the power supplies.
Memory
Bank X
(0-7)
DIMM xA DIMM
xB
DIMM xC DIMM
xD
The specified DIMM has failed—the
DIMM must be replaced.
If all the LEDs for a rank (0-7) are lit and
the Memory Config Error LED is lit then
the DIMMs in the specified rank are
mismatched—replace mismatched DIMM.
Check
Power
Supply
n/a n/a n/a One of the power supply or power supply
fans has failed—replace the power supply.
The faulty power supply LED (located on
power supply) will be lit.
Memory
Config
Error
n/a n/a n/a The DIMMs in a rank are mismatched. All
the DIMMs in the specified rank (0-7) will
be lit.
Processor
Config
Error
n/a n/a n/a The processors are mismatched—replace
mismatched processor.
Missing
Component
n/a n/a n/a A required component(s) is not installed in
the system and thus preventing power up.
System
Temp
n/a n/a n/a The internal temperature of the server
has exceeded the warning or critical level.
Check
Event Log
n/a n/a n/a An event has occurred that requires
attention.
Table 2-5 QuickFind Diagnostic Panel LEDs (Continued)
Item LED 0 LED 1 LED 2 LED 3 Details
