134
PSE ID Max Current Peak Average Remaining Powered
(W) (W) (W) (W) Guaranteed(W) Ports
35 300 200 230 205 100 20
# (Centralized devices in IRF mode.) Display power usage statistics for all PoE power supplies and PSEs.
<Sysname> display poe power-usage
Slot 1 :
PoE Current Power : 600 W
PoE Max Power : 2000 W
PoE Max Guaranteed Power : 1000 W
PoE Remaining Allocable Power : 800 W
PoE Remaining Guaranteed Power : 600 W
Powered PoE Ports : 60
Statistics by PSE:
PSE ID Max Current Peak Average Remaining Powered
(W) (W) (W) (W) Guaranteed(W) Ports
4 300 200 230 205 100 20
7 400 300 345 290 200 30
10 500 100 120 110 300 10
Slot 2 :
PoE Current Power : 600 W
PoE Max Power : 2000 W
PoE Max Guaranteed Power : 1000 W
PoE Remaining Allocable Power : 800 W
PoE Remaining Guaranteed Power : 600 W
Powered PoE Ports : 60
Statistics by PSE:
PSE ID Max Current Peak Average Remaining Powered
(W) (W) (W) (W) Guaranteed(W) Ports
35 300 200 230 205 100 20
Table 25 Command output
Field Description
Chassis 1
PoE power and PSE power information for member device 1. (Distributed
devices in IRF mode.)
Slot 1
PoE power and PSE power information for member device 1.
(Centralized devices in IRF mode.)
PoE Current Power Total power that has been consumed by PSEs.
PoE Max Power Maximum PoE power.
PoE Max Guaranteed Power Maximum power that can be supplied to critical PSEs.
PoE Remaining Allocable Power
Remaining allocable PoE power = Maximum PoE power – Total
maximum power of all PoE-enabled PSEs.
PoE Remaining Guaranteed Power
Remaining guaranteed PoE power = Maximum guaranteed PoE power –
Total maximum power of all critical PSEs.
Typically, the maximum guaranteed PoE power is equal to the maximum
PoE power.
Powered PoE Ports Number of PIs that are supplying power.
