HP omnibook OmniBook XE2 User Manual

2-22 Removal and Replacement HP OmniBook XE2
Component Removal Procedures Additional Steps (See figures on pages 4-2, 4-4)
Bottom Case Keyboard (see page 2-9).
Top case (see page 2-15).
CPU and motherboard
(see page 2-17).
Remove heatsink, drives, PCAs, CPU module, and
motherboard (page 2-17).
CD-ROM Drive Keyboard (see page 2-9).
Top case (see page 2-15).
Remove heatsink (page 2-17).
CPU Module / CPU See page 2-17. Remove heatsink (page 2-17).
Fan See page 2-7.
Floppy Disk Drive Keyboard (see page 2-9).
Top case (see page 2-15).
Remove heatsink (page 2-17).
Hard Disk Drive See page 2-6.
Heatsink Keyboard (page 2-9).
Top case (see page 2-15).
LED PCA Keyboard (see page 2-9).
Top case (see page 2-15).
Remove heatsink (page 2-17).
Modem PCA Keyboard (see page 2-9).
Top case (see page 2-15).
Remove heatsink (page 2-17).
Motherboard See page 2-17.
RAM Board See page 2-4.
