Removal and Replacement Procedures

Maintenance and Service Guide 5–3

Section Description

# of Screws Removed

5.4 Hard Drive 2 loosened to remove each

hard drive cover

4 removed to disassemble

each hard drive

5.5 Computer Feet 0

5.6 Memory Module 2 loosened to remove the

memory module compartment

cover

5.7 RTC Battery 0

5.8 Mini Card Module 2

To prevent an unresponsive system and the display of a

warning message, install only a Mini Card device

authorized for use in your computer by the governmental

agency that regulates wireless devices in your country or

region. If you install a device and then receive a warning

message, remove the device to restore computer

functionality. Then contact technical support by selecting

Start > Help and Support > Contact support.

5.9 Optical Drive 1 to remove the optical drive

2 to remove the optical drive

bracket

5.10 Switch Cover 6

5.11 Keyboard 4

5.12 Speaker Assembly 2

5.13 Power Button Board 1

Disassembly Sequence Chart

(Continued)
