5–56 Maintenance and Service Guide
Removal and Replacement Procedures
5.17 Audio Board
1. Prepare the computer for disassembly (Section 5.3) and
remove the following components:
❏ Hard drive (Section 5.4)
❏ Optical drive (Section 5.9)
❏ Switch cover (Section 5.10)
❏ Keyboard (Section 5.11)
❏ Speaker assembly (Section 5.12)
❏ Display assembly (Section 5.14)
❏ Top cover (Section 5.15)
Audio Board Spare Part Number Information
Audio board (includes audio board cable and infrared lens)
for use with dv9000
Audio board (includes audio board cable and infrared lens)
for use with dv9200
432986-001
438369-001
