1–22 Maintenance and Service Guide

Product Description

1. 5 D e s i g n ove r v i ew

This section presents a design overview of key parts and features

of the computer. Refer to Chapter 3, “Illustrated Parts Catalog,”

to identify replacement parts, and Chapter 5, “Removal and

Replacement Procedures,” for disassembly steps.

The system board provides the following device connections:

■ AMD Mobile Turion and Mobile AMD Sempron processors

■ Audio

■ Display

■ ExpressCard

■ Fan

■ Hard drive

■ Intel Core Duo processors

■ Keyboard and TouchPad

■ Memory module

■ Mini Card module

CAUTION: To properly ventilate the computer, allow at least a 7.6-cm

(3-inch) clearance on the left and right sides of the computer.

The computer uses an electric fan for ventilation. The fan is

controlled by a temperature sensor and is designed to turn on

automatically when high temperature conditions exist. These

conditions are affected by high external temperatures, system

power consumption, power management/battery conservation

configurations, battery fast charging, and software. Exhaust air is

displaced through the ventilation grill located on the left side of

the computer.
