5–60 Maintenance and Service Guide
Removal and Replacement Procedures
5.19 USB/Magnetic Board
1. Prepare the computer for disassembly (Section 5.3) and
remove the following components:
❏ Hard drive (Section 5.4)
❏ Optical drive (Section 5.9)
❏ Switch cover (Section 5.10)
❏ Keyboard (Section 5.11)
❏ Speaker assembly (Section 5.12)
❏ Display assembly (Section 5.14)
❏ Top cover (Section 5.15)
USB/Magnetic Board Spare Part Number Information
USB/magnetic board (includes USB/magnetic board cable) for
use with dv9000
USB/magnetic board (includes USB/magnetic board cable) for
use with dv9200
432990-001
438370-001
