Removal and Replacement Procedures
Maintenance and Service Guide 5–47
5.15 Top Cover
1. Prepare the computer for disassembly (Section 5.3) and
remove the following components:
❏ Hard drive (Section 5.4)
❏ Optical drive (Section 5.9)
❏ Switch cover (Section 5.10)
❏ Keyboard (Section 5.11)
❏ Speaker assembly (Section 5.12)
❏ Display assembly (Section 5.14)
Top Cover Spare Part Number Information
Top cover (includes TouchPad and TouchPad cable) for use with
model dv9000
Top cover (includes TouchPad and TouchPad cable) for use with
dv9200
432977-001
442919-001
