Removal and Replacement Procedures
Maintenance and Service Guide 5–65
5.21 Top Cover Support Trim
1. Prepare the computer for disassembly (Section 5.3) and
remove the following components:
❏ Hard drive (Section 5.4)
❏ Optical drive (Section 5.9)
❏ Switch cover (Section 5.10)
❏ Keyboard (Section 5.11)
❏ Speaker assembly (Section 5.12)
❏ Display assembly (Section 5.14)
❏ Top cover (Section 5.15)
Top Cover Support Trim Spare Part Number Information
Top cover support trim 432978-001
