Maintenance and Service Guide A–1
A
Screw Listing
This appendix provides specification and reference information
for the screws used in the computer.
The four Phillips PM3.0×3.0 screws used to secure the hard drive
bracket to the hard drive are included in the Hard Drive Bracket
Kit, spare part number 434106-001.
Phillips PM3.0×3.0 Screw Locations
Table A-1
Phillips PM3.0×3.0 Screw
Color Qty. Length Thread
Head
Width
Silver 4 3.0 mm 3.0 mm 5.0 mm
Where used:
4 screws that secure the hard drive bracket to the hard drive (documented in
Section 5.4)
mm
