Product Description
Maintenance and Service Guide 1–21
3 Optical drive Reads an optical disc.
4 Secondary hard drive bay Holds an optional secondary hard drive.
Primary hard drive bay Hold the primary hard drive.
5 Vents (6) Enable airflow to cool internal
components.
✎
The computer fan starts up
automatically to cool internal
components and prevent
overheating. It is normal for the
internal fan to cycle on and off
during routine operation.
6 Memory module
compartment
Contains the memory module slots, the
Mini Card slot, and the RTC battery.
Table 1-8
Bottom Components
(Continued)
Item Component Function
