Removal and Replacement Procedures
Maintenance and Service Guide 5–29
10. Release the ZIF connector 1 to which the keyboard cable is
connected and disconnect the keyboard cable 2 from the
system board.
Disconnecting the Keyboard Cable
11. Remove the keyboard.
Reverse the above procedure to install the keyboard.
