Removal and Replacement Procedures
Maintenance and Service Guide 5–31
6. Remove the two black Phillips PM2.5×5.0 screws 1 that
secure the speaker assembly to the computer.
7. Remove the speaker assembly 2.
Removing the Speaker Assembly
Reverse the above procedure to install the speaker assembly.
