Removal and Replacement Procedures
Maintenance and Service Guide 5–33
6. Remove the silver Phillips PM2.5×5.0 screw 1 that secures
the power button board to the computer.
7. Remove the power button board 2.
Removing the Power Button Board
Reverse the above procedure to install the power button board.
