HP Pavilion dv9000 Maintenance And Service Guide

Removal and Replacement Procedures
Maintenance and Service Guide 5–45
28. If it is necessary to replace the microphones and cables,
release the retention tabs 1 built into the display enclosure
that secure the microphone cables to the display enclosure.
29. Remove the microphone receivers 2 from the clips in the
display enclosure.
30. Remove the microphone cables 3 from the display enclosure.
Removing the Microphones
Display Assembly Subcomponents
Spare Part Number Information
Microphones 432961-001

HP Pavilion dv9000 Specifications

General

Wireless	802.11a/b/g
Audio	Altec Lansing speakers
Processor	Intel Core 2 Duo / AMD Turion 64 X2
Display	17-inch WXGA+
Graphics	NVIDIA GeForce Go 7600
Operating System	Windows Vista or Windows XP
Optical Drive	DVD±RW
USB Ports	3
Ports	VGA, Ethernet
Card Reader	5-in-1
RAM	1 GB to 4 GB
Bluetooth	Optional
