Removal and Replacement Procedures
Maintenance and Service Guide 5–71
2. Remove the two silver Phillips PM2.5×5.0 screws 1 that
secure the power connector assembly bracket to the
computer.
3. Remove the power connector assembly bracket 2.
Removing the Power Connector Assembly Bracket
