6–4 Maintenance and Service Guide
Specifications
Table 6-3
17.0-inch, WXGA+, TFT Display
Dimensions
Height
Width
Diagonal
23.00 cm
36.90 cm
43.40 cm
9.06 in
14.49 in
17.09 in
Number of colors Up to 16.8 million
Contrast ratio 200:1
Brightness 180 nits typical
Pixel resolution
Pitch
Format
Configuration
0.259 × 0.259 mm
1280 × 800
RGB vertical stripe
Backlight Edge lit
Character display 80 × 25
Total power consumption 4 W
Viewing angle +/-40° horizontal, +20/-40° vertical
typical
