IP Routing Features
Configuring OSPF
Example: To get OSPF virtual link information for IP address 10.0.8.33, enter
show ip ospf virtual-link 10.0.8.33. A display similar to the following is shown.
HPswitch# show ip ospf virtual-link 10.0.8.33
OSPF Virtual Interface Status for interface 10.0.8.33
Transit AreaID : 10.3.16.0
Neighbor Router : 10.0.8.33
Authentication : none Transit Delay : 1
Interface State : P2P Rtr Interval : 5
Events : 1 Hello Interval : 10
Dead Interval : 40
Figure 11-23.Example of Output for Show IP OSPF Virtual-Link < ip-addr >
In this display, these fields show the same type of information as described
for the general OSPF virtual link display: Transit Area ID, Neighbor Router,
Authentication, and Interface State. This display shows the following additional
information:
Table 11-15. CLI Display of OSPF Virtual Link Information – Specific IP Address
Field Description
Events The number of times the virtual link interface state has changed.
Transit delay The configured transit delay for the virtual link.
Rtr Interval The configured retransmit interval for the virtual link.
Hello Interval The configured hello interval for the virtual link.
Dead Interval The configured router dead interval for the virtual link
11-67
