Static Virtual LANs (VLANs)
Configuring VLANs
At the global config level, use:
HPswitch(config)# no vlan 100 tagged a1-a5
- or -
At the VLAN 100 context level, use:
HPswitch(vlan-100)# no tagged a1-a5
Note You cannot use these commands with dynamic VLANs. Attempting to do so
results in the message “VLAN already exists.” and no change occurs.
Web: Viewing and Configuring VLAN Parameters
In the web browser interface you can do the following:
■ Add VLANs
■ Rename VLANs
■ Remove VLANs
■ Configure VLAN tagging mode per-port
■ Configure GVRP mode
■ Select a new Primary VLAN
To configure other static VLAN port parameters, you will need to use either
the CLI or the menu interface (available by Telnet from the web browser
interface).
1. Click on the Configuration tab.
2. Click on
[Vlan Configuration].
3. Click on
[Add/Remove VLANs].
For web-based Help on how to use the web browser interface screen, click on
the
[?] button provided on the web browser screen.
2-37
