Router Redundancy Using XRRP
Displaying XRRP Data
The keyword instance can be used to display statistics information for the
virtual router instance(s) on the switch. If no parameters are specified after
this keyword, the information for all virtual routers is displayed, otherwise
the information for the particular virtual router is displayed by specifying the
owner-router-number and the vlan-id in the command. In the example below,
the statistics information for the virtual router number 1 on VLAN 5 is
requested.
HPswitch(config)# show xrrp statistics instance 1 5
Statu s and Counters - XRRP Virtual Router Statistics Information
Owne r Router Number : 1
VLAN ID : 5
Oper ational State : Master
Up T ime : 64 mins
Pkts Rx : 0 Pkts Tx : 780
Zero Priority Rx : 0 Zero Priority Tx : 0
Bad Version Pkts : 0 Mismatched Pswd Pkts : 0
Mism atched IP Pkts : 0 Mismatched Interval Pkts : 0
Figure 12-12.Example of Output for Show XRRP Statistics Instance [<owner-router-number> <vlan-id>]
The keyword router can be used to display statistics information for the
specific router coordinator operating in the XRRP domain as shown in the
next example.
HPswitch(config)# show xrrp statistics router 2
St atus and Counters - XRRP Router Coordinator Statistics Information
R outer Number : 2
B ecome Master : 1
M aster Time : 76 mins
T ype1 Type 1 Type2 Typ e2 Unknow n
P kts Rx Pkts Tx Pkts Rx Pkt s Tx VLAN I D
- ----------- ------------ -------- ---- ------------ ------------
0 924 0 0 0
Figure 12-13.Example of Output for Show XRRP Statistics Router <router-num>
12-20
