32 HP ProLiant DL360 Generation 4 Server Maintenance and Service Guide
7. Remove the component from the server.
To replace the component, reverse the removal procedure.
SATA Backplane
1. Power down the server ("Powering Down the Server" on page 16).
2. Remove all SATA hard drives ("Hard Drive" on page 21
).
3. Eject the optical device ("Optical Device" on page 25
).
4. Extend or remove the server from the rack ("Extending the Server from the
Rack" on page 17
).
5. Remove the access panel ("Removing the Access Panel" on page 18
).
6. Remove the optical device and diskette drive interface ("Optical Device and
Diskette Drive Interface" on page 30
).
7. Disconnect all cables connected to the SATA backplane. For cable locations,
refer to the SATA cable routing (on page 51
) information.
