Removal and Replacement Procedures 35
2. Remove any expansion board installed in the assembly.
To replace the component, reverse the removal procedure.
PCI Riser Board
1. Remove the PCI Riser Board Assembly ("PCI Riser Board Assembly" on
page 33
).
2. Remove any expansion board installed in the assembly ("PCI-X or PCI
Express Expansion Board" on page 34
).
3. Remove the applicable PCI riser boards from the assembly:
IMPORTANT: When removing the two parts of the riser board, pay
attention to the orientation of the slots on each side. This information is
important for subsequent procedures.
