Removal and Replacement Procedures 41
2. Extend or remove the server from the rack ("Extending the Server from the
Rack" on page 17
).
3. Remove the access panel ("Removing the Access Panel" on page 18
).
NOTE: The server ships with at least two DIMMs installed in DIMM
slots 1A and 2A.
4. If necessary, remove the PCI Riser Board Assembly ("PCI Riser Board
Assembly" on page 33
).
5. Remove the DIMM.
CAUTION: Be sure to install DIMMs in the proper
configuration. Refer to the Documentation CD.
CAUTION: Use only Compaq branded or HP DIMMs. DIMMs
from other sources may adversely affect data integrity.
IMPORTANT: DIMMs do not seat fully if turned the wrong way.
To replace a DIMM, align the DIMM with the slot and insert the DIMM firmly.
When fully seated, the DIMM slot latches lock into place.
