Server Component Identification 71
The front panel health LEDs indicate only the current hardware status. In some
situations, HP SIM may report server status differently than the health LEDs
because the software tracks more system attributes.
System LED and
Color
Internal Health
LED Color
Status
Processor failure,
socket X (Amber)
Red One or more of the following conditions may exist:
•
•
•
•
•
Processor in socket X has failed.
Processor in socket X failed over to the offline spare.
Processor X is not installed in the socket.
Processor X is unsupported.
ROM detects a failed processor during POST.
Amber Processor in socket X is in a pre-failure condition.
Processor failure,
both sockets (Amber)
Red Processor types are mismatched.
PPM failure (Amber) Red PPM has failed.
DIMM failure, slot X
(Amber)
Red •
•
DIMM in slot X has failed.
DIMM in slot X is an unsupported type, and no valid
memory exists in another bank.
Amber •
•
•
DIMM in slot X has reached single-bit correctable
error threshold.
DIMM in slot X is in a pre-failure condition.
DIMM in slot X is an unsupported type, but valid
memory exists in another bank.
DIMM failure, all slots
in one bank (Amber)
Red No valid or usable memory is installed in the system.
Overtemperature
(Amber)
Amber The Health Driver has detected a cautionary temperature
level.
Red The server has detected a hardware critical temperature
level.
Riser interlock
(Amber)
Red The PCI riser board assembly is not seated.
Online spare memory
(Amber)
Amber Bank X failed over to the online spare memory bank.
