To create recovery discs, your computer must have a DVD writer. Use any of the following types of discs
(purchased separately): DVD+R, DVD+R DL, DVD-R, DVD-R DL, or DVD±RW. The discs you use will depend on
the type of optical drive you are using.
Creating recovery discs
NOTE: The Windows 7 operating system DVD can be created only once. The option to create that media will
not be available after you create a Windows DVD.
To create the Windows DVD:
1. Select Start > All Programs > Productivity and Tools > HP Recovery Disc Creator.
2. Select Windows disk.
3. From the drop-down menu, select the drive for burning the recovery media.
4. Click the Create button to start the burning process. Label the disc after you create it, and store it in a
secure place.
After the Windows 7 operating system DVD has been created, create the Driver Recovery DVD:
1. Select Start > All Programs > Productivity and Tools > HP Recovery Disc Creator.
2. Select Driver disk.
3. From the drop-down menu, select the drive for burning the recovery media.
4. Click the Create button to start the burning process. Label the disc after you create it, and store it in a
secure place.
Backing up your information
You should create your initial backup immediately after initial system setup. As you add new software and
data les, you should continue to back up your system on a regular basis to maintain a reasonably current
backup. Your initial and subsequent backups allow you to restore your data and settings if a failure occurs.
You can back up your information to an optional external hard drive, a network drive, or discs.
Note the following when backing up:
Store personal les in the Documents library, and back it up regularly.
Back up templates that are stored in their associated directories.
Save customized settings that appear in a window, toolbar, or menu bar by taking a screen shot of your
settings. The screen shot can be a time-saver if you have to reset your preferences.
When backing up to discs, number each disc after removing it from the drive.
NOTE: For detailed instructions on various backup and restore options, perform a search for these topics in
Help and Support. To access Help and Support, select Start > Help and Support.
NOTE: You may be prompted by User Account Control for your permission or password when you perform
certain tasks. To continue a task, select the appropriate option. For information about User Account Control,
see Help and Support: Select Start > Help and Support.
To create a backup using Windows Backup and Restore:
NOTE: The backup process may take over an hour, depending on le size and the speed of the computer.
126 Chapter 8 System backup and recovery

Table of Contents

Other manuals for HP proone 400 g2

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP proone 400 g2 and is the answer not in the manual?

HP proone 400 g2 Specifications

General IconGeneral
Panel typeTN
Screen shapeFlat
LED backlightYes
Display diagonal20 \
Display resolution1600 x 900 pixels
Native aspect ratio16:9
Recovery operating systemWindows 10 Pro
Operating system installedWindows 7 Professional
Operating system architecture64-bit
Product typeAll-in-One PC
Motherboard chipsetIntel® H110
Tcase66 °C
Bus typeDMI3
SteppingS0
Processor codeSR2HE
Processor cache3 MB
Processor cores2
Processor modeli3-6100T
System bus rate8 GT/s
Processor familyIntel® Core™ i3
Processor seriesIntel Core i3-6100 Desktop series
Processor socketLGA 1151 (Socket H4)
Processor threads4
Processor codenameSkylake
Processor frequency3.2 GHz
Processor cache typeSmart Cache
Processor lithography14 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version3.0
PCI Express configurations2x8, 1x8+2x4, 1x16
Thermal Design Power (TDP)35 W
Maximum number of PCI Express lanes16
Memory types supported by processorDDR3L-SDRAM, DDR4-SDRAM
Memory voltage supported by processor1.35 V
Memory channels supported by processorDual
Memory clock speeds supported by processor1333, 1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)34.1 GB/s
Maximum internal memory supported by processor64 GB
Internal memory8 GB
Memory slots typeSO-DIMM
Memory clock speed2133 MHz
Internal memory typeDDR4-SDRAM
Maximum internal memory16 GB
Memory layout (slots x size)1 x 4 GB
HDD speed7200 RPM
HDD interfaceSATA
Storage mediaHDD
Optical drive typeDVD Super Multi
Total storage capacity500 GB
Compatible memory cardsNot supported
Number of HDDs installed1
On-board graphics card ID1912
Discrete graphics card modelNot available
On-board graphics card modelIntel® HD Graphics 530
Maximum on-board graphics card memory1.74 GB
On-board graphics card OpenGL version4.4
On-board graphics card base frequency350 MHz
On-board graphics card DirectX version12.0
On-board graphics card dynamic frequency (max)950 MHz
Number of displays supported (on-board graphics)3
Audio systemDTS Studio Sound
AC adapter power90 W
Total megapixels1 MP
Camera resolution1920 x 1080 pixels
Wi-Fi standardsWi-Fi 5 (802.11ac)
Ethernet LAN data rates10, 100, 1000 Mbit/s
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity0
Sustainability certificatesENERGY STAR
Product colorSilver
Country of originChina
Scalability1S
Processor ARK ID90734
Processor package size37.5 x 37.5 mm
Supported instruction setsSSE4.1, AVX 2.0, SSE4.2
Thermal solution specificationPCG 2015A
Intel Secure Key Technology version1.00
Intel Stable Image Platform Program (SIPP) version0.00
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)347.5 mm
Width (with stand)496.71 mm
Height (with stand)58.7 mm
Weight (with stand)5450 g
