Cleaning the Computer Case
Follow all safety precautions in General cleaning safety precautions on page 17 before cleaning the computer.
To clean the computer case, follow the procedures described below:
To remove light stains or dirt, use plain water with a clean, lint-free cloth or swab.
For stronger stains, use a mild dishwashing liquid diluted with water. Rinse well by wiping it with a cloth
or swab dampened with clear water.
For stubborn stains, use isopropyl (rubbing) alcohol. No rinsing is needed as the alcohol will evaporate
quickly and not leave a residue.
After cleaning, always wipe the unit with a clean, lint-free cloth.
Occasionally clean the air vents on the computer. Lint and other foreign matter can block the vents and
limit the airow.
Cleaning the keyboard
Follow all safety precautions in General cleaning safety precautions on page 17 before cleaning the keyboard.
To clean the tops of the keys or the keyboard body, follow the procedures described in Cleaning the Computer
Case on page 18.
When cleaning debris from under the keys, review all rules in General cleaning safety precautions on page 17
before following these procedures:
CAUTION: Use safety glasses equipped with side shields before attempting to clean debris from under the
keys.
Visible debris underneath or between the keys may be removed by vacuuming or shaking.
Canned, pressurized air may be used to clean debris from under the keys. Caution should be used as too
much air pressure can dislodge lubricants applied under the wide keys.
If you remove a key, use a specially designed key puller to prevent damage to the keys. This tool is
available through many electronic supply outlets.
CAUTION: Never remove a wide leveled key (like the space bar) from the keyboard. If these keys are
improperly removed or installed, the keyboard may not function properly.
Cleaning under a key may be done with a swab moistened with isopropyl alcohol and squeezed out. Be
careful not to wipe away lubricants necessary for proper key functions. Use tweezers to remove any
bers or dirt in conned areas. Allow the parts to air dry before reassembly.
Cleaning the monitor
Wipe the monitor screen with a clean cloth moistened with water or with a towelette designed for
cleaning monitors. Do not use sprays or aerosols directly on the screen; the liquid may seep into the
housing and damage a component. Never use solvents or ammable liquids on the monitor.
To clean the monitor body follow the procedures in Cleaning the Computer Case on page 18.
18 Chapter 3 Routine care, SATA drive guidelines, and disassembly preparation

Table of Contents

Other manuals for HP proone 400 g2

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP proone 400 g2 and is the answer not in the manual?

HP proone 400 g2 Specifications

General IconGeneral
Panel typeTN
Screen shapeFlat
LED backlightYes
Display diagonal20 \
Display resolution1600 x 900 pixels
Native aspect ratio16:9
Recovery operating systemWindows 10 Pro
Operating system installedWindows 7 Professional
Operating system architecture64-bit
Product typeAll-in-One PC
Motherboard chipsetIntel® H110
Tcase66 °C
Bus typeDMI3
SteppingS0
Processor codeSR2HE
Processor cache3 MB
Processor cores2
Processor modeli3-6100T
System bus rate8 GT/s
Processor familyIntel® Core™ i3
Processor seriesIntel Core i3-6100 Desktop series
Processor socketLGA 1151 (Socket H4)
Processor threads4
Processor codenameSkylake
Processor frequency3.2 GHz
Processor cache typeSmart Cache
Processor lithography14 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version3.0
PCI Express configurations2x8, 1x8+2x4, 1x16
Thermal Design Power (TDP)35 W
Maximum number of PCI Express lanes16
Memory types supported by processorDDR3L-SDRAM, DDR4-SDRAM
Memory voltage supported by processor1.35 V
Memory channels supported by processorDual
Memory clock speeds supported by processor1333, 1600, 1866, 2133 MHz
Memory bandwidth supported by processor (max)34.1 GB/s
Maximum internal memory supported by processor64 GB
Internal memory8 GB
Memory slots typeSO-DIMM
Memory clock speed2133 MHz
Internal memory typeDDR4-SDRAM
Maximum internal memory16 GB
Memory layout (slots x size)1 x 4 GB
HDD speed7200 RPM
HDD interfaceSATA
Storage mediaHDD
Optical drive typeDVD Super Multi
Total storage capacity500 GB
Compatible memory cardsNot supported
Number of HDDs installed1
On-board graphics card ID1912
Discrete graphics card modelNot available
On-board graphics card modelIntel® HD Graphics 530
Maximum on-board graphics card memory1.74 GB
On-board graphics card OpenGL version4.4
On-board graphics card base frequency350 MHz
On-board graphics card DirectX version12.0
On-board graphics card dynamic frequency (max)950 MHz
Number of displays supported (on-board graphics)3
Audio systemDTS Studio Sound
AC adapter power90 W
Total megapixels1 MP
Camera resolution1920 x 1080 pixels
Wi-Fi standardsWi-Fi 5 (802.11ac)
Ethernet LAN data rates10, 100, 1000 Mbit/s
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity0
Sustainability certificatesENERGY STAR
Product colorSilver
Country of originChina
Scalability1S
Processor ARK ID90734
Processor package size37.5 x 37.5 mm
Supported instruction setsSSE4.1, AVX 2.0, SSE4.2
Thermal solution specificationPCG 2015A
Intel Secure Key Technology version1.00
Intel Stable Image Platform Program (SIPP) version0.00
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)347.5 mm
Width (with stand)496.71 mm
Height (with stand)58.7 mm
Weight (with stand)5450 g
