Right trim
To remove the right trim:
1. Prepare the computer for disassembly (see Preparing to disassemble the computer on page 22).
2. Remove the rear port cover (see Rear port cover on page 23).
3. Remove the stand (see Attaching and removing a stand on page 24).
4. Remove the access panel (see Access panel on page 28).
5. Remove the optical drive (see Replacing the optical drive on page 31).
6. Remove the top trim (see Top trim on page 34).
60 Chapter 4 Removal and Replacement Procedures
