HP Q METER 4342A - Page 98

Section VI
Table 6-2
Model 4342A
Reference
Designation
A8
A8Cl
A8 c2
A8C3
A8C4
A8C5
A8C6 0180-0097
A8C7 0180-0982
A8C8
0180-0982
A8C9 0180-1735
A8C10
0180-1735
A8CRl 1901-0026
A8CR2 1901-0026
A8CR3
1901-0026
A8CR4 1901-0026
A8CR5
1902-0041
A8CR6 1901-0025
A8CR7 1901-0025
A8CR8 1901-0025
A8CR9 1901-0025
A8CRlO 1901-0026
A8CRll 1901-0026
A8CR12 1901-0026
A8CR13 1901-0026
A8CR14
1901-0025
A8CR15
1901-0025
A8CR16 1901-0025
A8CR17 1910-0016
A8CR18 1902-0041
A8CR19
1901-0025
A8CR20 1901-0026
A8CR21 1901-0026
A8CR22 1902-3182
A8Ql
A8Q2
A8Q3
A8Q4
A8Q5
Table 6-2. Reference Designation Index (Cont’d)
Part No.
04342-7708 POWER SUPPLY & ALC AMPLIFIER ASS’Y
04342-8708 BOARD:BLANK PC
0150-0121 C:FXD CER 0. 1nF -20% +80% 50VDCW
0180-0291
C:FXD TA 1pF 10% 35VDCW
0180-0097 C:FXD TA 47/.~F 10% 35VDCW
0150-0121
C :FXD CER 0. 1lF -20% +80% 50VDCW
0180-0291 C:FXD TA 1nF 10% 35VDCW
1854-0039 TRANSISTOR:SILICON NPN 2N3053
1854-0071 TRANSISTOR:SILICON NPN 2N3391
1854-0215 TRANSISTOR :SILICON NPN 2N3904
1854-0215 TRANSISTOR:SILICON NPN 2N3904
1854-0071 TRANSISTOR:SILICON NPN 2N3391
Description
C:FXD TA 47yF 10% 35VDCW
C:FXD ELECT 1pF -10% +lOO% 250VDCW
C:FXD ELECT 1nF -10% +lOO% 250VDCW
C:FXD TA 0.22nF 10% 35VDCW
C:FXD TA 0.22pF 10% 35VDCW
SEMICON DEVICE :DIODE SILICON
SEMICON DEVICE :DIODE SILICON
SEMICON DEVICE :DIODE SILICON
SEMICON DEVICE :DIODE SILICON
SEMICON DEVICE:DIODE BREAKDOWN 5.11V 5% 400mW
SEMICON DEVICE :DIODE SILICON
SEMICON DEVICE :DIODE SILICON
SEMICON DEVICE :DIODE SILICON
SEMICON DEVICE:DIODE SILICON
SEMICON DEVICE :DIODE SILICON
SEMICON DEVICE :DIODE SILICON
SEMICON DEVICE :DIODE SILICON
SEMICON DEVICE :DIODE SILICON
SEMICON DEVICE :DIODE SILICON
SEMICON DEVICE :DIODE SILICON
SEMICON DEVICE:DIODE SILICON
SEMICON DEVICE:DIODE GERMANIUM
SEMICON DEVICE:DIODE BREAKDOWN 5.11V 5% 400mW
SEMICON DEVICE :DIODE SILICON
SEMICON DEVICE :DIODE SILICON
SEMICON DEVICE :DIODE SILICON
SEMICON DEVICE:DIODE BREAKDOWN 12.1V 5% 400mW
Note
See list of abbreviations in introduction to this section
