3. Detach the touchpad cable (3) from the top cover and touchpad. (The touchpad cable is attached to the top
cover and touchpad with double-sided adhesive at two locations.)
4. Remove the touchpad cable.
Reverse this procedure to install the touchpad cable.
Touchpad
To remove the touchpad, use this procedure and illustration.
Table
5-6 Touchpad descriptions and part numbers
Description Spare part number
Touchpad:
In natural silver nish M22166-001
In nightfall black nish M22165-001
In Poseidon blue nish M22167-001
NOTE: The touchpad spare part kit does not include the touchpad cable. The touchpad cable is available using spare part number
M22152-001.
Before removing the touchpad, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 37).
2. Remove the bottom cover (Bottom cover on page 37).
3. Remove the battery (see Battery on page 38).
Remove the touchpad:
ENWW Component replacement procedures 45
