3. Remove the battery (see Battery on page 38).
4. Remove the system board (see System board on page 46).
Remove the connector board cable:
1. Release the ZIF connector (1) to which the connector board cable is connected, and then disconnect the
connector board cable from the connector board.
2. Remove the connector board cable (2).
Reverse this procedure to install the connector board cable.
Connector board
To remove the connector board, use this procedure and illustration.
Table
5-9 Connector board description and part number
Description Spare part number
Connector board M22163-001
NOTE: The connector board spare part kit does not include the connector board cable. The connector board cable is available usiung
spare part number M22150-001.
Before removing the connector board, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 37).
2. Remove the bottom cover (Bottom cover on page 37).
3. Remove the battery (see Battery on page 38).
4. Remove the system board (see System board on page 46).
Remove the connector board:
ENWW Component replacement procedures 51

HP Spectre x360 14 Specifications

General

Display Size	13.5 inches
Graphics	Intel Iris Xe Graphics
Wireless	Wi-Fi 6, Bluetooth 5.0
Audio	Bang & Olufsen, quad speakers
Resolution	3000 x 2000 pixels
Processor	Intel Core i7
RAM	16 GB
Storage	1 TB SSD
Operating System	Windows 10
Battery Life	Up to 17 hours
Weight	2.95 lbs (1.34 kg)
Ports	2 x Thunderbolt 4, 1 x USB-A, 1 x headphone/microphone combo
Webcam	720p
Battery	4-cell, 66 Wh Li-ion polymer
Color	Nightfall Black
