HP Uninterruptible Power System T1000 XR and T1500 XR Models User Guide 1-1
HP CONFIDENTIAL Codename: Sherman Part Number: 216164-002 Last Saved On: 8/19/02 4:21 PM
1
Overview
This chapter contains a general overview of the HP UPS, including an introduction to the
model configurations, power management software, available hardware options, and
warranties. Read this chapter to become familiar with the features of the UPS before
operating the unit.
UPS Features
The following features make this UPS versatile and easy to use:
• Communications port for data exchange with the host computer
• Network Transient Protector
• Load segment control
• Load power protection up to 1000 VA/700 W (T1000 XR NA and T1000 XR H INT’L
models), 1440 VA/1050 W (T1500 XR NA model), or 1500 VA/1050 W (T1500 XR JPN
and T1500 XR H INT’L models)
• Support for UPS power management software
• Support for HP hardware option cards, extending the power management capabilities of
the UPS
• Support for HP Extended Runtime Modules (ERMs), options that extend the available
runtime of the UPS
• Ease of use and configuration
Communications Port
The UPS includes a communications port for data exchange with a host computer.
CAUTION: Use only the specific cables supplied with the UPS to connect the
communications port to the host computer.

HP T1000 XR Specifications

General

Output Power Capacity (Watts)	900 Watts
Topology	Line Interactive
Rack Height	2U
Waveform Type	Sine Wave
Nominal Output Voltage	230V
Nominal Input Voltage	230V
Typical Backup Time at Half Load	15 minutes
Interface Port	USB
Device Type	UPS
Input Voltage	230V
Output Voltage	230V
Frequency	50/60 Hz
Waveform	Sine Wave
Typical Recharge Time	3 hours
Operating Temperature	0 to 40°C
Storage Temperature	-15 to 45°C
Relative Humidity	0 to 95% non-condensing
Output Power Capacity	1000 VA
Input Connection	IEC C14
Battery Type	Sealed Lead Acid
Transfer Time	4 ms
Dimensions	438 x 89 x 482 mm
