Specifications
C-2 HP Uninterruptible Power System T1000 XR and T1500 XR Models User Guide
HP CONFIDENTIAL Codename: Sherman Part Number: 216164-002 Last Saved On: 8/19/02 4:21 PM
Input Specifications
Table C-3: Input Specifications—UPS T1000 XR and T1500 XR Models
UPS Model
Utility
Voltage
Frequency
(Hz)
Default
Settings
Nominal
Voltage
(VAC)
Available
Settings
Utility Voltage
(VAC)
Power Cord Supplied
T1000 XR NA 50/60 120 100, 110, 120,
127
1
Non-detachable power
cord with NEMA 5-15 plug
T1000 XR H INT’L 50/60 230 220, 230, 240 Input power receptacle
(IEC-320-C14) for
country-specific plug
attachment
T1500 XR NA 50/60 120 110, 120, 127
1
Non-detachable power
cord with NEMA 5-15 plug
T1500 XR JPN 50/60 100 100
2
Non-detachable power
cord with NEMA 5-20 plug
T1500 XR H INT’L 50/60 230 220, 230, 240 Input power receptacle
(IEC-320-C14) for
country-specific plug
attachment
Note: 1 120 on battery
2 110 on battery
Before connecting devices, verify that the UPS will not overload by checking that the rating
of the devices do not exceed the capacity of the UPS. Evenly distribute connected devices
throughout all load segments. Do not exceed the rating of individual receptacles. Connect
devices according to shutdown preference.
After checking that the UPS will not overload, connect the power cords from the devices to
the appropriate output receptacles of the UPS.
WARNING: To prevent risk of personal injury from electric shock, the
UPS T1000 XR H INT’L and T1500 XR H INT’L models are not suitable for installation
where the total earth (ground) conductor leakage current for all connected devices
exceeds 3.5 mA.
