HP T1000 XR - Output Specifications

Specifications
HP Uninterruptible Power System T1000 XR and T1500 XR Models User Guide C-3
HP CONFIDENTIAL Codename: Sherman Part Number: 216164-002 Last Saved On: 8/19/02 4:21 PM
Output Specifications
Table C-4: Output Specifications—UPS T1000 XR and T1500 XR Models
UPS Model
Effective
VA
Nominal Power
Rating (W)
Load
Segment #
Output Receptacles
T1000 XR NA 1000 700 1 3 x 5-15R
2 3 x 5-15R
T1000 XR H INT’L 1000 700 1 3 x IEC-320, C13
2 3 x IEC-320, C13
T1500 XR NA 1440 1050 1 3 x 5-15R
2 3 x 5-15R
T1500 XR JPN 1500 1050 1 3 x 5-15R
2 3 x 5-15R
T1500 XR H INT’L 1500 1050 1 3 x IEC-320, C13
2 3 x IEC-320, C13
