Overview
HP Uninterruptible Power System T1000 XR and T1500 XR Models User Guide 1-3
HP CONFIDENTIAL Codename: Sherman Part Number: 216164-002 Last Saved On: 8/19/02 4:21 PM
Front Panel
The front panel of the UPS is shown in Figure 1-1.
2
1
3
Figure 1-1: Front panel configuration
1 LED display
2 Control buttons
3 Battery compartment
For detailed information on using the control buttons and LED indicators, refer to the section,
“Front Panel Controls and LED Indicators,” in Chapter 2.
