HP T1000 XR User Manual

Regulatory Compliance Notices
HP Uninterruptible Power System T1000 XR and T1500 XR Models User Guide A-5
HP CONFIDENTIAL Codename: Sherman Part Number: 216164-002 Last Saved On: 8/19/02 4:21 PM
Battery Replacement Notice
The UPS is equipped with a sealed lead-acid battery pack. There is a danger of explosion and
risk of personal injury if the battery is incorrectly replaced or mistreated. Replacement is to
be done using the designated spare for this product. For more information about battery
replacement or proper disposal, contact your authorized reseller or your authorized service
provider.
WARNING: The UPS contains a sealed lead-acid battery pack. There is risk of fire and
burns if the battery pack is not properly handled. To reduce the risk of personal injury:
• Do not attempt to recharge the battery.
• Do not expose to temperatures higher than 60°C (140°F).
• Do not disassemble, crush, puncture, short external contacts, or dispose of in fire
or water.
• Replace only with the spare designated for this product.
Batteries, battery packs, and accumulators should not be disposed of together with the
general household waste. To forward them to recycling or proper disposal, use the
public collection system or return them to HP, your authorized HP Partners, or their
agents.

HP T1000 XR Specifications

General

Output Power Capacity (Watts)	900 Watts
Topology	Line Interactive
Rack Height	2U
Waveform Type	Sine Wave
Nominal Output Voltage	230V
Nominal Input Voltage	230V
Typical Backup Time at Half Load	15 minutes
Interface Port	USB
Device Type	UPS
Input Voltage	230V
Output Voltage	230V
Frequency	50/60 Hz
Waveform	Sine Wave
Typical Recharge Time	3 hours
Operating Temperature	0 to 40°C
Storage Temperature	-15 to 45°C
Relative Humidity	0 to 95% non-condensing
Output Power Capacity	1000 VA
Input Connection	IEC C14
Battery Type	Sealed Lead Acid
Transfer Time	4 ms
Dimensions	438 x 89 x 482 mm
