HP T1000 XR User Manual

Operation
HP Uninterruptible Power System T1000 XR and T1500 XR Models User Guide 2-5
HP CONFIDENTIAL Codename: Sherman Part Number: 216164-002 Last Saved On: 8/27/02 3:59 PM
Initiating a Self-Test
To initiate a self-test, press and hold the Test/Alarm Reset button (1) for three seconds.
1
Figure 2-4: Test/Alarm Reset button
Because a portion of the self-test requires battery power, the self-test cannot be initiated if the
batteries are less than 90 percent charged. If the UPS detects a problem, the appropriate LED
illuminates and an audible alarm may sound.
WARNING: To reduce the risk of electric shock from Earth (ground) conductor leakage
current, use the self-test procedure to check the UPS batteries (rather than unplugging
the UPS).
• For the meaning of individual LEDs, refer to “Front Panel Controls and LED Indicators,”
in this chapter.
• For information on what to do if the self-test detects a problem, refer to Chapter 5,
“Troubleshooting.”

HP T1000 XR Specifications

General

Output Power Capacity (Watts)	900 Watts
Topology	Line Interactive
Rack Height	2U
Waveform Type	Sine Wave
Nominal Output Voltage	230V
Nominal Input Voltage	230V
Typical Backup Time at Half Load	15 minutes
Interface Port	USB
Device Type	UPS
Input Voltage	230V
Output Voltage	230V
Frequency	50/60 Hz
Waveform	Sine Wave
Typical Recharge Time	3 hours
Operating Temperature	0 to 40°C
Storage Temperature	-15 to 45°C
Relative Humidity	0 to 95% non-condensing
Output Power Capacity	1000 VA
Input Connection	IEC C14
Battery Type	Sealed Lead Acid
Transfer Time	4 ms
Dimensions	438 x 89 x 482 mm
