Overview
1-2 HP Uninterruptible Power System T1000 XR and T1500 XR Models User Guide
HP CONFIDENTIAL Codename: Sherman Part Number: 216164-002 Last Saved On: 8/19/02 4:21 PM
Network Transient Protector
The UPS includes a Network Transient Protector (NTP) that provides surge protection for
connected communication devices.
CAUTION: To avoid damaging the equipment, do not connect the Network Transient
Protector to a digital PBX line. Connect either to an analog phone line or to a network.
UPS T1000 XR and T1500 XR Models
HP UPS T1000 XR and T1500 XR models include the following.
Table 1-1: UPS T1000 XR and T1500 XR Models
UPS Model
Kit Part
Number
Unit Part
Number
Series
Number
Comments
T1000 XR NA 204155-001 204203-001 EO3017 Domestic, low-voltage tower
with non-detachable
NEMA 5-15 plug
T1000 XR H INT’L 204155-B31 204203-002 EO3017i International, high-voltage
tower with detachable
country-specific plug
T1500 XR NA 204155-002 204203-003 EO3018 Domestic, low-voltage tower
with non-detachable
NEMA 5-15 plug
T1500 XR JPN 204155-291 204203-191 EO3018j Japanese, low-voltage tower
with non-detachable
NEMA 5-20 plug
T1500 XR H INT’L 204155-B32 204203-004 EO3018i International, high-voltage
tower with detachable
country-specific plug

HP T1000 XR Specifications

General

Output Power Capacity (Watts)	900 Watts
Topology	Line Interactive
Rack Height	2U
Waveform Type	Sine Wave
Nominal Output Voltage	230V
Nominal Input Voltage	230V
Typical Backup Time at Half Load	15 minutes
Interface Port	USB
Device Type	UPS
Input Voltage	230V
Output Voltage	230V
Frequency	50/60 Hz
Waveform	Sine Wave
Typical Recharge Time	3 hours
Operating Temperature	0 to 40°C
Storage Temperature	-15 to 45°C
Relative Humidity	0 to 95% non-condensing
Output Power Capacity	1000 VA
Input Connection	IEC C14
Battery Type	Sealed Lead Acid
Transfer Time	4 ms
Dimensions	438 x 89 x 482 mm
