HP T1000 XR User Manual

HP Uninterruptible Power System T1000 XR and T1500 XR Models User Guide C-1
HP CONFIDENTIAL Codename: Sherman Part Number: 216164-002 Last Saved On: 8/19/02 4:21 PM
C
Specifications
This appendix provides the physical, input, and output specifications for the UPS. Topics also
include battery descriptions, battery runtime estimates, and environmental requirements when
operating the UPS.
Physical Specifications
Table C-1: Physical Specifications—UPS T1000 XR Models
Feature Metric U.S.
Dimensions Width 163 mm 6.4 in
Height 241 mm 9.5 in
Depth* 411 mm 16.2 in
Weight 13 kg 34.5 lb
* With UPS front bezel installed
Table C-2: Physical Specifications—UPS T1500 XR Models
Feature Metric U.S.
Dimensions Width 163 mm 6.4 in
Height 241 mm 9.5 in
Depth* 462 mm 18.2 in
Weight 24 kg 55 lb
*With UPS front bezel installed

HP T1000 XR Specifications

General

Output Power Capacity (Watts)	900 Watts
Topology	Line Interactive
Rack Height	2U
Waveform Type	Sine Wave
Nominal Output Voltage	230V
Nominal Input Voltage	230V
Typical Backup Time at Half Load	15 minutes
Interface Port	USB
Device Type	UPS
Input Voltage	230V
Output Voltage	230V
Frequency	50/60 Hz
Waveform	Sine Wave
Typical Recharge Time	3 hours
Operating Temperature	0 to 40°C
Storage Temperature	-15 to 45°C
Relative Humidity	0 to 95% non-condensing
Output Power Capacity	1000 VA
Input Connection	IEC C14
Battery Type	Sealed Lead Acid
Transfer Time	4 ms
Dimensions	438 x 89 x 482 mm
