5–24 Startup Guide
Identifying Exterior Hardware
Front: Positioning and Security Features
Component Description
1
Rotation disk Rotates the tablet PC while it is
attached to the keyboard.
2
Docking alignment
notches (4)
Help guide the tablet PC and keyboard
into an optional Docking Station.
3
Keyboard latch When the tablet PC and keyboard are
closed, locks the tablet PC to the
keyboard:
■ Slide to the right to lock the
tablet PC to the keyboard.
■ Slide to the left to unlock the
tablet PC from the keyboard.
334201-001.book Page 24 Tuesday, August 19, 2003 11:17 AM
